BIGGER & BETTER!

Stessl Aluminium Plate Boats SEAHAWK

The Stessl Seahawk builds on it’s predecessor’s proven pedigree by providing even more cabin and deck space in a boat that’s been engineered to take you further – safer! With an improved Platetrix hull design, more deadrise and massive fuel capacity, the Seahawk provides a softer, more comfortable ride to get you to where the fish are. The true half cabin design provides full 6ft bunks for a contented nights rest, all while still providing acres of deck space for fighting that fish of a lifetime or just purely entertaining.

With an improved Platetrix hull design, more deadrise and massive fuel capacity, the Seahawk provides a softer, more comfortable ride to get you to where the fish are.

Has been engineered to take you further – safer!

TE_Trac_Logo_Green

BOAT
SPECIFICATIONS

Choose your hull size >>

535

Length Overall:  5.40m

Beam: 2.40m

Depth: 1.35m

Bottom Sheet:  4mm 5083 High Tensile

Side Sheet:  4mm 5052 Marine Grade

Transom:  XL

Weight (boat only):  610 kgs

Horsepower Rec:  90hp

Horsepower Max:  115hp

Pax:  5 ppl




Download Spec Sheet

Length Overall:  5.70m

Beam: 2.45m

Depth: 1.45m

Bottom Sheet:  4mm 5083 High Tensile

Side Sheet:  4mm 5052 Marine Grade

Transom:  XL

Weight (boat only):  650 kgs

Horsepower Rec:  115hp

Horsepower Max:  150hp

Pax:  6 ppl




Download Spec Sheet

Length Overall:  6.00m

Beam: 2.50m

Depth: 1.50m

Bottom Sheet:  4mm 5083 High Tensile

Side Sheet:  4mm 5052 Marine Grade

Transom:  XL

Weight (boat only):  710 kgs

Horsepower Rec:  140hp

Horsepower Max:  175hp

Pax:  6 ppl




Download Spec Sheet

Length Overall:  6.40m

Beam: 2.50m

Depth: 1.50m

Bottom Sheet:  4mm 5083 High Tensile

Side Sheet:  4mm 5052 Marine Grade

Transom:  XL

Weight (boat only):  765 kgs

Horsepower Rec:  150hp

Horsepower Max:  200hp

Pax:  7 ppl




Download Spec Sheet

Length Overall:  6.70m

Length Bow to Transom: 6.60m

Beam: 2.50m

Depth: 1.50m

Bottom Sheet:  5mm 5083 High Tensile

Side Sheet:  4mm 5052 Marine Grade

Transom:  XL

Weight (boat only):  960 kgs

Horsepower Rec:  175hp

Horsepower Max:  250hp

Pax:  7 ppl




Download Spec Sheet

Length Overall:  7.70m

Length Bow to Transom: 7.30m

Beam: 2.50m

Depth: 1.50m

Bottom Sheet:  5mm 5083 High Tensile

Side Sheet:  4mm 5052 Marine Grade

Transom:  XL

Weight (boat only):  1400 kgs

Horsepower Rec:  250hp

Horsepower Max:  350hp

Pax:  7 ppl




Download Spec Sheet

02. Seahawk

Diagram shows standard features and general configuration. Proportions will vary for each model. This drawing is not to scale. Measurements and weights subject to variation and should be used as a guide only.

DESIGN YOUR SEAHAWK
DEALERSHIP ENQUIRY

BOAT
OPTIONS

  • Two Tone Paint
  • Metallic Paint
  • Underfloor Kill tank
  • Bait Board
  • Bait Board with bait tank
  • Live bait tank in transom
  • Bimini
  • Front Clears
  • Side Clears
  • Electric Motor Mount
  • Self draining Welded floors
  • Targa Bar with Rod Holders
  • Double Dash
  • Enclosed Hard Top with Glass Windscreen and Sliding Windows (635 - 735 Only)

View Options Page For Stessl PlatetriX2 Series Boats

PlatetriX2 Boat Options

PHOTOS

Seahawk
Seahawk_2
Seahawk_3
Seahawk—1
Seahawk—2
Seahawk—3
Seahawk—4
Seahawk—5
Seahawk—6

BOAT SPECIFICATION
COMPARISONS

SPECIFICATIONS

535
565
595
635
665
735
4mm Bulkheads and frames fully welded to hull – not floating
✓
✓
✓
✓
✓
✓
Full height transom with twin boarding platforms
✓
✓
✓
✓
✓
✓
Walk through Transom door
✓
✓
✓
✓
✓
✓
Fully welded gunnels and side decks
✓
✓
✓
✓
✓
✓
Extruded Side Decks
✓
✓
✓
✓
✓
✓
Enclosed rear transom with twin hatches
✓
✓
✓
✓
✓
✓
Large aluminium anchor well
✓
✓
✓
✓
✓
✓
Aluminium Half cabin with opening hatch
✓
✓
✓
✓
✓
✓
Large cabin design allows for spacious 1500 mm bunks
✓
✕
✕
✕
✕
✕
Large cabin design allows for spacious 1800mm bunks
✕
✓
✓
✓
✓
✓
Large dash fascia for over size electronics
✓
✓
✓
✓
✓
✓
Tinted acrylic wrap around windscreen
✓
✓
✓
✓
✓
✓
Baystar Hydraulic Steering
✓
✓
✓
✓
✓
✓
Gussi Sports Steering wheel
✓
✓
✓
✓
✓
✓
Pedestal mounted Deluxe helm seats on slides & swivels
✓
✓
✓
✓
✓
✓
Folding rear lounge and backrest
✓
✓
✓
✓
✓
✓
Increased Wiring Gauge
✓
✓
✓
✓
✓
✓
5 gang switch panel with 12V socket
✓
✓
✓
✓
✓
✓
Anchor Winch Brackets
✓
✓
✓
✓
✓
✓
RAILBLAZA TracLoader Coaming
✓
✓
✓
✓
✓
✓
Automatic bilge pump
✓
✓
✓
✓
✓
✓
LED Navigation lights and Anchor light
✓
✓
✓
✓
✓
✓
Carpeted timber floor
✓
✓
✓
✓
✕
✕
Checker Plate Floor
✕
✕
✕
✕
✓
✓
Australian Standards Approved underfloor foam flotation
✓
✓
✓
✓
✕
✕
Long range aluminium 150 lt fuel tank with sender unit
✓
✕
✕
✕
✕
✕
Long range aluminium 175 ltr fuel tank with sender unit
✕
✓
✕
✕
✕
✕
Long range aluminium 200 ltr fuel tank with sender unit
✕
✕
✓
✕
✓
✕
Long range aluminium 250ltr fuel tank with sender unit
✕
✕
✕
✓
✕
✓
Long range 250 ltr aluminium fuel tank with 100ltr Auxiliary tank with sender units
✕
✕
✕
✕
✓
✓
Heavy-duty dive boarding ladder
✓
✓
✓
✓
✓
✓
High 32mm Bow rails
✓
✓
✓
✓
✓
✓
Heavy-duty bow sprit with double rollers and rope keepers
✓
✓
✓
✓
✓
✓
32mm Transom rails
✓
✓
✓
✓
✓
✓
32mm Side rails
✓
✓
✓
✓
✓
✓
Large side pockets x 2
✓
✓
✓
✓
✓
✓
Riveted aluminium Rod Holders x 4
✓
✓
✓
✓
✓
✓
Cast alloy cleats x 3
✓
✓
✓
✓
✓
✓
Drivers side footrest
✓
✓
✓
✓
✓
✓
Cup holders x 2
✓
✓
✓
✓
✓
✓
Transducer Brackets x 2
✓
✓
✓
✓
✓
✓
Painted White in and out
✓
✓
✓
✓
✓
✓
Custom decals
✓
✓
✓
✓
✓
✓
Railblaza Captains Pack
✓
✓
✓
✓
✓
✓
Enclosed Hard Top with Glass Windscreen and Sliding Windows
✕
✕
✕
✕
✓
✓
